Molecular sieve 5A

WRITER：admin 　JOIN IN：2015-12-21

CLASSES：Adsorbents

Products Introduction:

XR403 Molecular sieve 5A is an adsorbent used for desulphurization during nature gas purification process. Specially developed molecular sieves can also be used in PSA oxygen generator and PSA hydrogen purification process.

XR403 Molecular sieve 5A is made by synthetic zeolite powder 5A with selected mineral binder. XR403 Molecular sieve 5A has an effective pore opening of 5? (0.5nm), it can adsorb molecules which diameter less than 5? (0.5nm), is mainly used for desulphurization during nature gas purification process.

Characteristics:

lstable and excellent static and kinetic adsorption capacity

lhigher crush strength

Property	Unit	Bead		Pellet		Note
Property	Unit	8x12	4x8	1/16"	1/8"	Note
Static Water Adsorption	%wt	≥ 21.50	≥ 21.50	≥ 21.50	≥ 21.50	RH50%, 25℃
Crush Strength	N	≥ 30.00	≥ 80.00	≥ 30.00	≥ 70.00	Avg. 25 beads
Crush Strength	lbs	≥ 7.00	≥ 18.00	≥ 7.00	≥ 16.00	Avg. 25 beads
Bulk Density	g/ml	≥ 0.68	≥ 0.68	≥ 0.64	≥ 0.64	Settle
Bulk Density	lbs/ft³	≥ 42.00	≥ 42.00	≥ 40.00	≥ 40.00	Settled
Loss on Ignition	%wt	≤ 1.50	≤ 1.50	≤ 1.50	≤ 1.50	575℃, 1hr
Loss on Attrition	%wt	≤ 0.10	≤ 0.10	≤ 0.30	≤ 0.30	~
Particle Ratio	%	≥ 97.00	≥ 99.00	~	~	~

Application：

1. Adsorb H2O, CO2, H2S from sour natural gas streams, while decreasing COS formation.

2. Separation of normal- and iso-paraffins.

3. Production of high purity N2, O2, H2 and inert gases from mixed gas streams.

Storage:

lAvoid moisture, avoid scrolling, throw and sharp shocking during transportation, rainproof facilities should be readied..

lIt should be stored in dry and ventilated warehouse to prevent contamination or moisture.

Packaging information:

Type	Carton	Drum	Super sack
Bead	25kg/ 55lb	140 kg/ 208 lb	1000kg/ 2200 lb
Pellet	25kg/ 55lb	130 kg/ 286 lb	1000kg/2200 lb
