activated alumina, pseudoboehmite, Zibo XiangRun Environment Engineering Co., Ltd.

General Aluminas XR AA-101 activated alumina desiccant XR AA-132 activated alumina for PTA	Chloride/TBC Purification ●XR CL-104, CL-104E XR-107	Peroxide Purification ●XR AA-107
SRU Claus Catalysts ●-Activated alumina catalysts ●-Promoted alumina catalysts ●-Titania catalysts ●-Alumina/Titania composite catalysts ●-Bed supports	Water treatment/fluoride removal ●XR AA-105	Hydrocarbon purification XR AA-104 XR AA-125
KMNO4 impregnated with activated alumina ●XR2006®M	Catalyst carrier	Large pore volume activated alumina

●-Available in powder, granular, and spherical forms in standard and custom sizes
●-Impressive range of adsorbent products including desiccant, chloride adsorbent, and Claus Catalysts
●-pseudoboehmite, Boehmite and boehmite-based gamma alumina powders for chemical catalysts, catalyst binders and abrasives

Product Technical Parameter

Item		XR-101	XR-105	XR-107	XR-400	XR-135
appearance		white, sphere, odourless, insoluble in  water, innocuous
application		Adsorbent， Desicccant	defluorination	adsorption H2O2	catalyst carrier	Dehydrating and drying in air separation
Crystal		x-p	x-p	γ	γ	x-p
chemical composition	Al2O3 %	≥93	≥93	≥93	≥93	≥93
	Na2O %	≤0.40	≤0.3	0.3-1.0	≤0.35	≤0.4
LOI	%	6-8	6-8	≤8	≤5	6-8
bulk density	g/ml	≥0.75	≥0.75	0.65-0.8	0.45-0.95	≥0.75
surface area	㎡/g	≥340	≥300	220-280	10-380	≥350
pore volume	ml/g	≥0.45	≥0.42	≥0.45	≥0.45	≥0.45
Attrition Loss	%	≤0.1				≤0.1
Crushing strength(N/Particle)	ф1-2mm		≥40			≥50
	ф2-3mm	≥70	≥80	≥80	≥40	≥70
	ф3-5mm	≥160	≥120	≥100	≥60	≥160
	ф4-6mm	≥200		≥130	≥80	≥200
	ф5-7mm	≥240				≥240
	ф6-8mm	≥260				≥260

Regeneration of activated alumina
●In the drying of activated alumina, regeneration of activated alumina is necessary. The heating and desorption processes include heating, rinsing and cooling in three steps. The higher the heating temperature, the more complete the desorption regeneration. General heating regeneration temperature is about 350 ℃. The temperature of the activated alumina tower is generally raised to 280℃ for 4 hours. Heating rate of about 50 ℃ per hour. After the regeneration of the active alumina bed must be cooled before the adsorption operation, with the cooling gas to wash the bed, the gas should also be used to try not to contain water, cold gas flow and adsorption cycle of the same direction. When activated alumina is used for liquids such as propylene drying, it is necessary to first drive the liquid of the activated alumina bed at the time of regeneration, without any dead ends. Otherwise the residual liquid will react or carbonize upon heating, which will seriously affect the efficiency and operating life of the adsorption cycle.
●If the activated alumina has good quality, it will improve the life of activated alumina. Certainly, whatever bad or good, you should use desiccant regeneration for future application. But Good quality activated alumina performance could improve the life and drying situation. So please purchase activated alumina from standard activated alumina factory. Trust our company could offer you the best warranty.

Professional technical proposals:
●The specialists of our company can design the technical offer with recommendations of application adsorptive drying systems and purification of gas and-liquid flows.
●Designing of adsorption system;
●Calculations of needed quantity of adsorbents ,catalyst and alumina balls ;
●Selection of cycle time ;
●Recommendations on regeneration and cooling of the adsorbent;
●Filling instruction of adsorbents ,catalyst and alumina balls
●Technical guaranties on adsorbent operation.

Deliver, packing, Shipping and Serving:
●2-7 working days since payment receipt
●25kg/plastic bag, 150kg/new steel drum, 25kg/paper drum, 500kg/750kg/jumbo bag. The all could add wooden pallets, non-fumigation pallets and plastic pallets as your requirement.

FAQQ: Do you have professional team for our special activated alumina to satisfy our data requirement?A: Our engineer and technical team includes 8 people to research and develop activated alumina. Until now, we don't confront any trouble on the data.Q: How long is the service life?A: Usually, it is at least 2 years or 8000 hours.
